The xTool S1 40W(P1030509) is a high-performance, fully enclosed laser cutting and engraving system. As the most powerful version in the S1 series, it is designed for maximum productivity and heavy-duty cutting. With its 40W optical power, it can slice through thick materials in a single pass and handle high-volume projects with ease.

The machine is certified as a Class 1 laser product, meaning its filtering cover makes it safe to use without safety goggles. Key features include Pin-point positioning for extreme accuracy without camera distortion and 3D Curve Engraving, which allows the laser to automatically map and engrave on curved surfaces.

Included in package(P1030509)

-1 x xTool S1 20W: This is the main unit, including the enclosed safety machine and the 20W diode laser head. The 20W module is highly prized for its smaller laser spot size (0.08×0.06 mm), which allows for much finer detail in engravings compared to the 40W version, while still being powerful enough for most cutting tasks.

-1 x Air Assist 2.0_AUTO: This is the advanced version of the air pump. The AUTO feature means the software (XCS or LightBurn) automatically adjusts the airflow. It stays low or off during engraving to prevent dust from settling, and kicks into high gear during cutting to prevent charring and blow out flames.

-1 x Honeycomb Panel: This is an essential bed for cutting. It lifts your material off the solid base of the machine, allowing smoke and heat to escape underneath. This prevents "flashback" burns on the back of your wood or acrylic, ensuring a clean finish on both sides.

Technical Specifications

Laser Performance:

Optical Output Power: 40W

Laser Type: Diode (455 nm wavelength)

Max Working Speed: 600 mm/s

Laser Spot Size: 0.08 x 0.10 mm

Movement Precision: 0.01 mm

Work Area:

Working Area: 498 x 319 mm

Max Object Height: 42 mm (expandable to 125-133 mm with Riser Base)

Expansion: Compatible with AutoPassthrough for materials up to 3000 mm long.

Smart Features & Safety:

Focusing: Smart Auto-focus (automated distance measurement)

Flame Detection: 5-way sensor system with emergency stop

Security: Interlock system (stops when lid opens), Tilt and Impact sensors, Emergency Stop button.

Ventilation: High-speed exhaust fan built-in.

Software & Connectivity:

Software Support: xTool Creative Space (XCS), LightBurn

Operating Systems: Windows, macOS, iOS, Android

Connection: USB, Wi-Fi

File Formats: SVG, DXF, JPG, JPEG, PNG, BMP, TIF

Dimensions & Weight:

Outer Dimensions: 765 x 561 x 183 mm

Net Weight: approx. 20 kg

Cutting Capacity (40W - Single Pass):

Cherry wood / Basswood: up to 18-20 mm

Black Acrylic: up to 15 mm

Stainless Steel: up to 0.1 mm

Key Advantage of the 40W Model:

While the 20W model is better for ultra-fine engraving, the 40W (P1030509) is the powerhouse of the family. It is specifically built for users who prioritize cutting depth and speed. It significantly reduces production time for businesses or hobbyists working with thick wood and acrylic.
